Dormitory Building
WHAT IS A PREFAB MODULAR DOMITORY?
A prefab modular dormitory building is a factoryprefabricated, portable accommodation structure built with standardized modular units, designed to provide safe, comfortable, and quickly deployable lodging for workers, staff, students, or personnel in construction camps, mining sites, oilfields, military bases, disaster relief zones, industrial parks, and remote projects.
Each modular unit is fully prefabricated in the factory with complete structure, walls, roof, flooring, doors, windows, electrical wiring, and basic interior finishes. Modules are transported to the site and rapidly assembled into singlestory or multistory dormitory buildings, offering flexible layouts for bedrooms, corridors, rest areas, washrooms, and storage spaces.
PREFAB MODULAR DOMITORY BUILDING KEY FEATURE
Fast Installation & Ready for Occupancy
Fully prefabricated in the factory, our modular dormitories can be quickly assembled on site, greatly shortening construction time and enabling immediate use.
Sturdy & Durable Structure
Built with heavy-duty galvanized steel frame, ensuring high wind resistance, seismic performance, long service life and stability in harsh environments.
Comfortable Living Environment
High-performance sandwich panels provide excellent thermal insulation, sound insulation and energy efficiency, creating quiet and comfortable living space.
Flexible Layout & Expandable
Freely combinable into single rooms, multi-bed dormitories, corridors, toilets and shower rooms; can be built into multi-storey buildings to meet different capacity needs.
High Safety & Fireproof Standard
Equipped with fire-resistant materials, standard electrical system and safe wiring, fully complying with accommodation safety requirements.
Waterproof & Anti-corrosion
Integrated waterproof design and anti-corrosion treatment, ideal for rainy, humid, coastal and remote areas.
Movable & Reusable
Easy to dismantle, relocate and reassemble with low damage, suitable for temporary camps, long-term projects and repeated use.
Cost-effective & Low Maintenance
Eco-friendly & Clean Construction Factory prefabrication reduces on-site pollution; most materials are recyclable, green and environmentally friendly.
Eco-friendly & Clean Construction
Factory prefabrication reduces on-site pollution; most materials are recyclable, green and environmentally friendly.
PREFAB MODULAR DOMITORY BUILDING – TECHNICAL DATA
1. Structure
Frame: Q235B/Q355 cold-formed galvanized light steel | Anti-corrosion: Hot-dip galvanizing/powder coating | Service life: 15–25 years | Wind resistance: Up to 220 km/h | Seismic resistance: Grade 8
2. Standard Module Dimensions
Size (L×W×H): 5950×2440×2800mm (customizable 3m/6m/9m/12m length) | Floor height: 2.4–2.8m | Max storey: 3
3. Roof & Wall
Panel: 50/75/100mm EPS/rock wool/PU sandwich panel | Fire rating: Class A (rock wool)/Class B (EPS/PU) | Waterproof grade: Level II
4. Floor & Ceiling
Floor: 12–18mm fireproof cement fiber board + PVC/wood grain floor | Ceiling: PVC/mineral wool board | Load capacity: 2.0–3.0 kN/㎡
5. Doors & Windows
Door: Steel security/aluminum alloy door | Window: Aluminum alloy sliding window (double-layer glass) | Good air/water tightness
6. Electrical System
Voltage: 220V/380V (customizable) | Pre-installed distribution box (leakage protection) | LED lights + international standard sockets | Pre-wired (safe standard)
7. Optional Plumbing
Pre-installed PVC/PPR water pipes + integrated drainage | Optional: Toilet, shower, wash basin
8. Installation & Transport
Assembly: 1 day (single unit); 3–7 days (multi-unit) | Transport: 40ft HQ container/flatbed truck | Foundation: Simple concrete/steel base
COMPARISION: MODULAR VS TRADITIONAL
Factor | Prefab Modular | Traditional Construction |
Construction Time | 3–6 months | 9–15+ months |
On-Site Impact | Minimal (low noise/dust) | High (extended disruption) |
Quality Control | High (factory inspected) | Variable (subject to site conditions) |
Flexibility | Easy to move or expand | Permanent and difficult to change |
9. Capacity
4–12 beds/standard unit | Combined layout: Dorm + corridor + toilet + shower + laundry
WHERE IS MODULAR DOMITORY BUILDING USED ?
1. Industrial & Resource Sectors
Mining & Oil Camps: Often used in remote areas where traditional construction is impossible. These provide “man camps” for workers with integrated HVAC and plumbing.
Construction Site Housing: Temporary housing for engineers and laborers on large-scale infrastructure projects (like dams, bridges, or high-speed rail).
2. Institutional & Educational Use
University Housing: Many colleges use modular units to quickly expand student housing capacity or provide high-quality temporary dorms during campus renovations.
Boarding Schools: Cost-effective solutions for faculty and student residences in private or rural educational institutions.
3. Commercial & Workforce Solutions
Seasonal Staff Housing: Frequently used by ski resorts, national parks, or large agricultural farms to house seasonal employees.
Corporate Employee Quarters: Industrial parks or manufacturing hubs often build modular dorms nearby to reduce commute times for their workforce.
4. Emergency & Social Services
Disaster Relief: Rapidly deployed to provide safe, insulated housing for people displaced by natural disasters.
Military Barracks: Used for both semi-permanent training facilities and rapid-response operations due to their standardized dimensions and ease of transport.
Social Housing: Cities are increasingly using modular dorms as a fast-track solution for transitional housing or homeless shelters.
5. Specialized Facilities
Sports Training Centers: Used to house athletes during intensive training camps or tournaments.
Hospital Staff Quarters: Providing on-site accommodation for medical personnel in rural clinics or during health crises.
PREFAB MODULAR DOMITORY BUILDING FOR SALE
MODULAR CAMPS is a trusted and professional supplier of high-quality modular dormitory buildings, providing safe, comfortable and fast-deployment accommodation solutions for construction camps, mining sites, oilfields, industrial parks, schools, military bases, disaster relief and remote projects worldwide.
Our prefab dormitories feature sturdy steel structure, excellent thermal and sound insulation, flexible layout, fireproof performance and easy installation. We support customized design, reliable quality, on-time delivery and full after-sales service.
If you are looking for modular dormitory buildings for sale, please feel free to contact us for your best quotation and tailored project solution.
