Storage Container Houses

Storage Container Houses

Prefab modular storage containers are modular unit designed for individual or business use, offering a clean, climate-controlled, and highly secure environment for personal belongings or commercial inventory.

WHAT IS STORAGE CONTAINER HOUSE?

A prefabricated modular storage container building is a versatile structure combining robust construction with multipurpose functionality. Built on a heavyduty shipping container frame, it is fully factoryengineered with thermal insulation, ventilation, waterproofing, interior finishes, and integrated utilities. It retains the key advantages of containers: durability, wind and earthquake resistance, and easy transport, while supporting secure storage and safe temporary occupancy.

Suitable for highvalue equipment storage, material warehousing, tool rooms, utility rooms, and onsite duty rooms, it performs reliably in construction camps, mining sites, oilfields, ports, and harsh environments. Key benefits include rapid installation, mobility, reusability, low maintenance, and full compliance with international standards.

MODULAR STORAGE HOUSE FEATURE

Unmatched Security

Constructed from high-tensile Corten steel, featuring heavy-duty locking mechanisms and tamper-proof doors to protect against theft and vandalism.

Superior Climate Protection

Equipped with the same external sloped roof and high-grade insulation as our dining and bathroom modules, ensuring that sensitive stored items (electronics, chemicals, or dry goods) are protected from extreme heat and condensation.

Anti-Corrosive Finish

Treated with specialized marine-grade coatings to withstand high-salinity (coastal), tropical, and desert environments.

Customizable Interior

Can be fitted with industrial shelving, heavy-duty workbenches, reinforced flooring, and explosion-proof lighting for specialized industrial use.

TECHNICAL SPECIFICATION OF MODULAR STORAGE CONTAINERS

  1. TECHNICAL SPECIFICATION OF MODULAR STORAGE CONTAINERS
    1. Structural Frame & Shell
      Main Frame:Cold-formed, hot-dipped galvanized steel profiles (Q235 or Q345B grade).
      External Walls:colour bond corrugated panels for maximum impact resistance and rust prevention.
      Corner Castings:Standard ISO 1161 corner fittings for secure lifting, stacking (up to 3 levels), and transport.
    1. Roofing & Insulation System
    • Secondary External Roof:Specialized insulated sloped (pitched) roof designed to shed water rapidly and create a thermal air buffer.
    • Wall Insulation:50mm / 75mm / 100mm Rockwool or Polyurethane (PU) sandwich panels (Fire Rating: Class A).
    • Thermal Performance:Engineered to maintain stable internal temperatures in ambient heat exceeding 45°C.
    1. Flooring & Loading Capacity
    • Sub-floor:Galvanized steel purlins with moisture-proof fiber cement board or marine-grade plywood (28mm).
    • Surface Finish:Anti-slip aluminum checkered plate or heavy-duty industrial PVC.
    • Load Bearing:Floor Load: 250kg/m2 to 500kg/m2 (Customizable for heavy machinery).
    • Roof Load: 150kg/m2.
    1. Doors & Security
    • Primary Access:Double-wing heavy-duty steel doors with EPDM weather-strip seals.
    • Locking Mechanism:Integrated tamper-proof locking bars and a recessed “Lock Box” to prevent bolt-cutter access.
    • Optional:Industrial aluminum roll-up shutters for pallet access.
    1. Electrical & Ventilation
    • Electrical Standard:Pre-wired to CE
    • Lighting:IP65-rated vapor-proof LED batten lights.
    • Ventilation:Passive louvered vents with insect mesh or active solar-powered extraction fans to prevent condensation (“container rain”).
    1. Environmental Resistance
    • Coating:C3 high-durability paint system for high-salinity and coastal environments.
    • Seismic/Wind:Designed to withstand Wind Class C (up to 120km/h) and Seismic Magnitude

MODULAR STORAGE HOUSE CONTAINER ADVANTAGE

Rapid Construction

Units can be ready for use in just two months, much faster than traditional construction.

Cost-Efficiency

Factory-controlled production reduces material waste and avoids weather delays, lowering total costs.

Extreme Durability

Built from heavy-duty shipping containers, they resist fire, termites, and extreme weather.

Scalability & Modularity

Standardized modules can be stacked or combined for flexible space expansion.

CARGO CONTAINER HOUSE APPLICATION

On-site storage for construction, mining, and oil & gas projects

Warehouse for tools, equipment, materials, and high-value goods

Temporary workshops, maintenance rooms, and utility spaces

Secure storage in remote areas, ports, yards, and industrial sites

Emergency storage for disaster relief and temporary operations

Expandable storage solutions for factories, farms, and logistics centers

FAQ

20ft flatpack container house, 6–12 units per 40ft HQ, Exact quantity depends on panel thickness and design.
Yes, it is fully weather-proof. It is windproof, waterproof, sun-proof, corrosion-resistant and can adapt to most outdoor climates.
The standard floor load capacity for our prefab storage container house is 200 kg/m² at least. For a 20ft unit, this is about 2800–3200 kg total floor load. We also offer a heavy-duty floor option with a load capacity up to 300–500 kg/m² (about 4300–7200 kg per 20ft unit) for heavy storage, equipment, and industrial use.
Yes, we can provide ISO9001, CE, and SGS test reports including wind load and snow load certification. All certificates and test documents are available for your customs clearance and project approval.
